Globe RainX The101 Bricked

Qawe_1423 · Sun at 12:50 PM

TS na load na sya sa preloader kaso loop lang sya preloader_b dahil sa cert vfy fail.
Ito po UART log ko

Pll init start...
Pll init Done!!
mtcmos Start..
efuse of id : hsmtop is 1
mtcmos Done!
PLL Preloader mode
PLL Preloader mode ret 0
#T#PLL=2
bandgap filter: 0x1000C010 = 0x100F00
pcie 0x112800c0 = 0xFC1
#T#GPIO=0
[DDR Reserve] DRM_DEBUG_CTL (0x1000d030): 0x83F1
[DDR Reserve] WDT_DEBUG_CTL_2(0x10007048): 0x1FFFF
[DDR Reserve] WDT_DEBUG_CTL_3(0x100070A8): 0x218000
[DDR Reserve] MTK_DRM_DEBUG_0_REG(0x1000D500): 0xC
[DDR Reserve] DRAMC_AO_CHA + 0xD00(0x10230D00): 0x0
[DDR Reserve] DDRPHY_AO_CHA + 0x1520(0x10239520): 0x0
[DDR Reserve] DRAMC_NAO_CHA + 0x80(0x10234080): 0x40060386
[DDR Reserve] DRAMC_NAO_CHA + 0x84(0x10234084): 0x10000000
[DDR Reserve] DRAMC_NAO_CHA + 0x88(0x10234088): 0x0
[DDR Reserve] DRAMC_AO_CHB + 0xD00(0x10240D00): 0x0
[DDR Reserve] DDRPHY_AO_CHB + 0x1520(0x10249520): 0x0
[DDR Reserve] DRAMC_NAO_CHB + 0x80(0x10244080): 0x40060386
[DDR Reserve] DRAMC_NAO_CHB + 0x84(0x10244084): 0x10000000
[DDR Reserve] DRAMC_NAO_CHB + 0x88(0x10244088): 0x0
[RGU] rst from: pl
[RGU] MODE: 0x35
[RGU] STA: 0x40000000
[RGU] LENGTH: 0xFFE0
[RGU] INTERVAL: 0xFFF
[RGU] SWSYSRST: 0x0
[RGU] LATCH_CTL: 0x21E71
[RGU] NONRST_REG: 0x0
[RGU] NONRST_REG2: 0x24002000
[RGU] DEBUG_CTL: 0x0
[RGU] DEBUG_1_REG: 0x40000000
[RGU] parse g_rgu_status: 2 (0x2)
[RGU] Set NONRST_REG to 0x40000000
[RGU] mtk_wdt_mode_config mode value=30, tmp:22000030
[DOE_ENV]get_env apwdt_en
[RGU] mtk_wdt_mode_config mode value=7D, tmp:2200007D
[RGU] mtk_wdt_reset_deglitch_enable: MTK_WDT_RSTDEG_EN1(8000A357), MTK_WDT_RSTDE G_EN2(800067D2)
[RGU] rgu_update_reg: 0, bits: 0xC000, addr: 0x10007040, val: 0x0
[RGU] rgu_update_reg: 0, bits: 0x300, addr: 0x100070A0, val: 0x0
[RGU] mtk_wdt_pre_init: MTK_WDT_DEBUG_CTL(0x0)
[RGU] mtk_wdt_pre_init: MTK_WDT_DEBUG_CTL2(0x0)
[RGU] mtk_wdt_pre_init: MTK_WDT_LATCH_CTL(0x21E71)
[DOE_ENV]get_env apwdt_en
[DOE_ENV]get_env apwdt_en
[DOE_ENV]get_env apwdt_en
[RGU] mtk_wdt_pre_init: MTK_WDT_REQ_MODE(1F0073), MTK_WDT_REQ_IRQ_EN(1B0070)
#T#WDT_PRE=21
RAM_CONSOLE_PL using SRAM
RAM_CONSOLE_PL start: 0x11D000, size: 0x800, sig: 0x43474244
RAM_CONSOLE_PL preloader last status: 0x0 0x0 0x0
RAM_CONSOLE_PL wdt status (0x2)=0x2
#T#Ram console=2
[PMIF] PLL_ULPOSC1_CON0/1/2 0x38A954 0x52E000 0x400000
[PMIF] ULPOSC1 K done: 261M
[pmifclkmgr_set_spmi_m_clk] done
[pmifclkmgr_set_spmi_p_clk] done
#T#PMIFCLKMGR=2
[SPMI] spmi_read_check done, slvid:4
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA2B, data=0x0, cmd=6
record write addr=0xA2B, data=0x29, cmd=3
record read addr=0xA2C, data=0x0, cmd=6
record write addr=0xA2C, data=0x47, cmd=3
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA2B, data=0x29, cmd=6
record write addr=0xA2B, data=0x0, cmd=3
record read addr=0xA2C, data=0x47, cmd=6
record write addr=0xA2C, data=0x0, cmd=3
record read addr=0x18, data=0x6, cmd=6
record write addr=0x42C, data=0x80, cmd=3(the last)
[SPMI] spmi_read_check done, slvid:4
[SPMI] rcs_en dly:0, pol:1, sampl:0x1
[SPMI] spmi_read_check done, slvid:5
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
[SPMI] spmi_read_check done, slvid:5
[SPMI] rcs_en dly:0, pol:1, sampl:0x1
#T#SPMI=11
[SPMI] spmi_read_check done, slvid:4
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
#T#SPMI_P=1
#T#I2C=0
DATE_CODE_YY:0, DATE_CODE_WW:0
[SegCode] Segment Code:0x2, PROJECT_CODE:0x0, FAB_CODE:0x0, RW_STA:0x992, CTL:0x 0, DCM:0x7
#T#DEVINFO=2
[PMIC]Preloader Start
[PMIC] CHIP Code = 0x3030
[PMIC]POWER_HOLD :0x1
[PMIC]TOP_RST_STATUS[0x13C]=0x48
[PMIC]PONSTS[0xC]=0x24
[PMIC]POFFSTS[0xE]=0x400
[PMIC]TOPSTS[0x18]=0x6
[pmic_check_rst] AP Watchdog
[PMIC]just_rst = 0
[PMIC]RG_RSV_SWREG[0xA0D]=0x0
[pwrkey_dbg_status] powerkey:0 count=0(ms) g_pwrkey_release=0
[pmic_wdt_set] TOP_RST_MISC1=0x25
register vmd12 OK
register vrfdig OK
register vcore OK
register vmd11 OK
register vsram_md OK
register vsram_core OK
register vsram_proc OK
register vsram_rfdig OK
register vio18_2 OK
register vmdd2_no_used OK
register vefuse OK
register vio18_1 OK
register vmddr OK
register vmddq OK
[MT6315]S5 RG_SLV_ID[0x136]=0xB5
[MT6315]S5 TOP_RST_STATUS[0x129]=0x3
[MT6315]S5 POFFSTS[0xC]=0x0
[MT6315]S5 RGS_POFFSTS[0xA0F]=0x0
[MT6315]S5 PG_SDN_STS0[0xF]=0xF
[MT6315]S5 OC_SDN_STS0[0x10]=0x0
[MT6315]S5 BUCK_OC_SDN_STS[0x1416]=0x0
[MT6315]S5 BUCK_OC_SDN_EN[0x1451]=0x1F
[MT6315]S5 TOP_RST_MISC[0x126]=0x4
register vproc OK
[MT6315]latch vproc 750000 uV(0x44)
register vmdd2 OK
[MT6315]latch vmdd2 1125000 uV(0xEE)
[MT6315]S5 set TOP_RST_MISC=0x3
0xFFFF:0xFFFF:0xFFFF:0xFFFF:0x4694:0xA83B:0xFB89:0x1EF6

S5)
[MT6315]mt6315_spmi_probe done
[PMIC]Init done
[pmic_enable_smart_reset] smart_en:0, smart_sdn_en:0
#T#PMIC=19
vproc/vsram run as hw default
[RGU] mtk_wdt_mode_config mode value=30, tmp:22000030
[RGU] mtk_wdt_mode_config mode value=7D, tmp:2200007D
[RGU] g_rgu_status: 2 (0x2)
[DOE_ENV]get_env apwdt_en
[RGU] bypass pwrkey: set
#T#WDT_INIT=3
RAM_CONSOLE_PL wdt status (0x2)=0x2
#T#Ram console=0
[SD0] Host controller intialization start
MSDC0 HCLK_MUX[0x1000_0020][17:16] = 1, pdn = 0, CLK_MUX[0x1000_0020][26:24] = 1 , pdn = 0, CLK_CG[0x1000_1094] bit2 = 0, bit6 = 0
MSDC0 MODE5[10005350] = 0x11111000 should: 0x11111???
MSDC0 MODE6[10005360] = 0x01111111 should: 0x?1111111
MSDC0 IES [11E00030] = 0x001FFFFF should: 0x????1FFE
MSDC0 SMT [11E000D0] = 0x000FFFFF should: 0x?????FFF
MSDC0 TDSEL0_0[11E000F0] = 0x00000000,[11E00100] = 0x00000000 should: 0x000000 00MSDC0, should: 0x????0000
MSDC0 RDSEL0[11E00090] = 0x00000000, [11E000A0] = 0x00000000, [11E000B0] = 0x000 00000 should: 0x00000000 ,should: 0x00000000 ,should: 0x??????00
MSDC0 DRV0 [11E00000] = 0x09249249, [11E00010] = 0x00249249 should: 0x?92492 49, should: 0x???????9
PUPD/R1/R0: dat/cmd:0/0/1, clk/dst: 1/1/0
MSDC0 PUPD0 [11E00050] = 0x0003F401 should: 0x?????401
MSDC0 R0 [11E00070] = 0x0003EBFE should: 0x?????BFE
MSDC0 R1 [11E00080] = 0x00001401 should: 0x?????401
[SD0] SET_CLK(260kHz): SCLK(260kHz) MODE(0) DDR(0) DIV(400) DS(0) RS(0)
[SD0] Host controller intialization done
[mmc_init]: msdc0 start mmc_init_card()
[mmc_init_card]: start
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
[SD0] Switch to High-Speed mode!
[SD0] Switch to SDR buswidth
[SD0] SET_CLK(260kHz): SCLK(260kHz) MODE(0) DDR(0) DIV(400) DS(0) RS(0)
[SD0] Size: 29820 MB, Max.Speed: 52000 kHz, blklen(512), nblks(61071360)
[SD0] Initialized, eMMC45
[SD0] SET_CLK(52000kHz): SCLK(52000kHz) MODE(0) DDR(0) DIV(2) DS(0) RS(0)
[mmc_init_card]: finish successfully
#T#Boot dev init=168
[PLFM] Init Boot Device: OK(0)
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
[AB] Current boot: Preloader_a
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[QL_AB] metadata.slots[0].priority:15,metadata.slots[1].priority:0.
[AB] ab_suffix: _a, ab_retry: 0, ab_boot_success: 1
[ROM_INFO] 'v131074'

[LIB] Loading SEC config
[LIB] Name =
[LIB] Config = 0x22, 0x11
0x31,0x41,0x35,0x32
GCPU Enhance,PL_V1.4

[SEC] reading seccfg
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
0x0,0x0,0x0,0x0,0x0,0x0,0x0,0x0,
[LIB] seclib_img_auth_load_sig [LIB] CFG read size '0x2000' '0x3C'
[LIB] SEC CFG doesn't exist
[SEC] init fail '0x103000'
#T#Sec lib init=30
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
boot_part: 1
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
part name=loader_ext_a
[SEC_POLICY] reached the end, use default policy
[SEC_POLICY] sboot_state = 0x1
[SEC_POLICY] lock_state(default) = 0x4
img_auth_required=1
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
sbc_en = 0
[SBC] cert verify, part = loader_ext_a, img = loader_ext_dram...fail, ret = 0x10 1017
cert vfy fail
<ASSERT> /101g/mtk/package/boot/preloader/platform/mt6890/src/core/main.c:line 1 047 0
PL fatal error...
PL delay for Long Press Reboot
[PLFM] emergency download mode(timeout: 5s).
[RGU] mtk_arch_reset at pre-loader!
[RGU] mtk_wdt_reset WDT MODE=35

angel031 · Sun at 3:43 PM

San po nakaka kuw ang required file img (rootfs_a.img / rootfs_b.img), stuck rin 101 ko, gamit ko Fusion firmware v7.2.02.g, penge naman po link ng dump files

edcyreysase · Sun at 3:57 PM

angel031 said:
San po nakaka kuw ang required file img (rootfs_a.img / rootfs_b.img), stuck rin 101 ko, gamit ko Fusion firmware v7.2.02.g, penge naman po link ng dump files

You do not have permission to view the full content of this post. Log in or register now.
eto po

edcyreysase · Sun at 4:13 PM

Qawe_1423 said:
TS na load na sya sa preloader kaso loop lang sya preloader_b dahil sa cert vfy fail.
Ito po UART log ko

Pll init start...
Pll init Done!!
mtcmos Start..
efuse of id : hsmtop is 1
mtcmos Done!
PLL Preloader mode
PLL Preloader mode ret 0
#T#PLL=2
bandgap filter: 0x1000C010 = 0x100F00
pcie 0x112800c0 = 0xFC1
#T#GPIO=0
[DDR Reserve] DRM_DEBUG_CTL (0x1000d030): 0x83F1
[DDR Reserve] WDT_DEBUG_CTL_2(0x10007048): 0x1FFFF
[DDR Reserve] WDT_DEBUG_CTL_3(0x100070A8): 0x218000
[DDR Reserve] MTK_DRM_DEBUG_0_REG(0x1000D500): 0xC
[DDR Reserve] DRAMC_AO_CHA + 0xD00(0x10230D00): 0x0
[DDR Reserve] DDRPHY_AO_CHA + 0x1520(0x10239520): 0x0
[DDR Reserve] DRAMC_NAO_CHA + 0x80(0x10234080): 0x40060386
[DDR Reserve] DRAMC_NAO_CHA + 0x84(0x10234084): 0x10000000
[DDR Reserve] DRAMC_NAO_CHA + 0x88(0x10234088): 0x0
[DDR Reserve] DRAMC_AO_CHB + 0xD00(0x10240D00): 0x0
[DDR Reserve] DDRPHY_AO_CHB + 0x1520(0x10249520): 0x0
[DDR Reserve] DRAMC_NAO_CHB + 0x80(0x10244080): 0x40060386
[DDR Reserve] DRAMC_NAO_CHB + 0x84(0x10244084): 0x10000000
[DDR Reserve] DRAMC_NAO_CHB + 0x88(0x10244088): 0x0
[RGU] rst from: pl
[RGU] MODE: 0x35
[RGU] STA: 0x40000000
[RGU] LENGTH: 0xFFE0
[RGU] INTERVAL: 0xFFF
[RGU] SWSYSRST: 0x0
[RGU] LATCH_CTL: 0x21E71
[RGU] NONRST_REG: 0x0
[RGU] NONRST_REG2: 0x24002000
[RGU] DEBUG_CTL: 0x0
[RGU] DEBUG_1_REG: 0x40000000
[RGU] parse g_rgu_status: 2 (0x2)
[RGU] Set NONRST_REG to 0x40000000
[RGU] mtk_wdt_mode_config mode value=30, tmp:22000030
[DOE_ENV]get_env apwdt_en
[RGU] mtk_wdt_mode_config mode value=7D, tmp:2200007D
[RGU] mtk_wdt_reset_deglitch_enable: MTK_WDT_RSTDEG_EN1(8000A357), MTK_WDT_RSTDE G_EN2(800067D2)
[RGU] rgu_update_reg: 0, bits: 0xC000, addr: 0x10007040, val: 0x0
[RGU] rgu_update_reg: 0, bits: 0x300, addr: 0x100070A0, val: 0x0
[RGU] mtk_wdt_pre_init: MTK_WDT_DEBUG_CTL(0x0)
[RGU] mtk_wdt_pre_init: MTK_WDT_DEBUG_CTL2(0x0)
[RGU] mtk_wdt_pre_init: MTK_WDT_LATCH_CTL(0x21E71)
[DOE_ENV]get_env apwdt_en
[DOE_ENV]get_env apwdt_en
[DOE_ENV]get_env apwdt_en
[RGU] mtk_wdt_pre_init: MTK_WDT_REQ_MODE(1F0073), MTK_WDT_REQ_IRQ_EN(1B0070)
#T#WDT_PRE=21
RAM_CONSOLE_PL using SRAM
RAM_CONSOLE_PL start: 0x11D000, size: 0x800, sig: 0x43474244
RAM_CONSOLE_PL preloader last status: 0x0 0x0 0x0
RAM_CONSOLE_PL wdt status (0x2)=0x2
#T#Ram console=2
[PMIF] PLL_ULPOSC1_CON0/1/2 0x38A954 0x52E000 0x400000
[PMIF] ULPOSC1 K done: 261M
[pmifclkmgr_set_spmi_m_clk] done
[pmifclkmgr_set_spmi_p_clk] done
#T#PMIFCLKMGR=2
[SPMI] spmi_read_check done, slvid:4
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA2B, data=0x0, cmd=6
record write addr=0xA2B, data=0x29, cmd=3
record read addr=0xA2C, data=0x0, cmd=6
record write addr=0xA2C, data=0x47, cmd=3
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA0F, data=0x20, cmd=6
record write addr=0xA0F, data=0x20, cmd=3
record read addr=0xA2B, data=0x29, cmd=6
record write addr=0xA2B, data=0x0, cmd=3
record read addr=0xA2C, data=0x47, cmd=6
record write addr=0xA2C, data=0x0, cmd=3
record read addr=0x18, data=0x6, cmd=6
record write addr=0x42C, data=0x80, cmd=3(the last)
[SPMI] spmi_read_check done, slvid:4
[SPMI] rcs_en dly:0, pol:1, sampl:0x1
[SPMI] spmi_read_check done, slvid:5
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
[SPMI] spmi_read_check done, slvid:5
[SPMI] rcs_en dly:0, pol:1, sampl:0x1
#T#SPMI=11
[SPMI] spmi_read_check done, slvid:4
[SPMI] non-rcs dly:0, pol:1, sampl:0x1
#T#SPMI_P=1
#T#I2C=0
DATE_CODE_YY:0, DATE_CODE_WW:0
[SegCode] Segment Code:0x2, PROJECT_CODE:0x0, FAB_CODE:0x0, RW_STA:0x992, CTL:0x 0, DCM:0x7
#T#DEVINFO=2
[PMIC]Preloader Start
[PMIC] CHIP Code = 0x3030
[PMIC]POWER_HOLD :0x1
[PMIC]TOP_RST_STATUS[0x13C]=0x48
[PMIC]PONSTS[0xC]=0x24
[PMIC]POFFSTS[0xE]=0x400
[PMIC]TOPSTS[0x18]=0x6
[pmic_check_rst] AP Watchdog
[PMIC]just_rst = 0
[PMIC]RG_RSV_SWREG[0xA0D]=0x0
[pwrkey_dbg_status] powerkey:0 count=0(ms) g_pwrkey_release=0
[pmic_wdt_set] TOP_RST_MISC1=0x25
register vmd12 OK
register vrfdig OK
register vcore OK
register vmd11 OK
register vsram_md OK
register vsram_core OK
register vsram_proc OK
register vsram_rfdig OK
register vio18_2 OK
register vmdd2_no_used OK
register vefuse OK
register vio18_1 OK
register vmddr OK
register vmddq OK
[MT6315]S5 RG_SLV_ID[0x136]=0xB5
[MT6315]S5 TOP_RST_STATUS[0x129]=0x3
[MT6315]S5 POFFSTS[0xC]=0x0
[MT6315]S5 RGS_POFFSTS[0xA0F]=0x0
[MT6315]S5 PG_SDN_STS0[0xF]=0xF
[MT6315]S5 OC_SDN_STS0[0x10]=0x0
[MT6315]S5 BUCK_OC_SDN_STS[0x1416]=0x0
[MT6315]S5 BUCK_OC_SDN_EN[0x1451]=0x1F
[MT6315]S5 TOP_RST_MISC[0x126]=0x4
register vproc OK
[MT6315]latch vproc 750000 uV(0x44)
register vmdd2 OK
[MT6315]latch vmdd2 1125000 uV(0xEE)
[MT6315]S5 set TOP_RST_MISC=0x3
0xFFFF:0xFFFF:0xFFFF:0xFFFF:0x4694:0xA83B:0xFB89:0x1EF6S5)
[MT6315]mt6315_spmi_probe done
[PMIC]Init done
[pmic_enable_smart_reset] smart_en:0, smart_sdn_en:0
#T#PMIC=19
vproc/vsram run as hw default
[RGU] mtk_wdt_mode_config mode value=30, tmp:22000030
[RGU] mtk_wdt_mode_config mode value=7D, tmp:2200007D
[RGU] g_rgu_status: 2 (0x2)
[DOE_ENV]get_env apwdt_en
[RGU] bypass pwrkey: set
#T#WDT_INIT=3
RAM_CONSOLE_PL wdt status (0x2)=0x2
#T#Ram console=0
[SD0] Host controller intialization start
MSDC0 HCLK_MUX[0x1000_0020][17:16] = 1, pdn = 0, CLK_MUX[0x1000_0020][26:24] = 1 , pdn = 0, CLK_CG[0x1000_1094] bit2 = 0, bit6 = 0
MSDC0 MODE5[10005350] = 0x11111000 should: 0x11111???
MSDC0 MODE6[10005360] = 0x01111111 should: 0x?1111111
MSDC0 IES [11E00030] = 0x001FFFFF should: 0x????1FFE
MSDC0 SMT [11E000D0] = 0x000FFFFF should: 0x?????FFF
MSDC0 TDSEL0_0[11E000F0] = 0x00000000,[11E00100] = 0x00000000 should: 0x000000 00MSDC0, should: 0x????0000
MSDC0 RDSEL0[11E00090] = 0x00000000, [11E000A0] = 0x00000000, [11E000B0] = 0x000 00000 should: 0x00000000 ,should: 0x00000000 ,should: 0x??????00
MSDC0 DRV0 [11E00000] = 0x09249249, [11E00010] = 0x00249249 should: 0x?92492 49, should: 0x???????9
PUPD/R1/R0: dat/cmd:0/0/1, clk/dst: 1/1/0
MSDC0 PUPD0 [11E00050] = 0x0003F401 should: 0x?????401
MSDC0 R0 [11E00070] = 0x0003EBFE should: 0x?????BFE
MSDC0 R1 [11E00080] = 0x00001401 should: 0x?????401
[SD0] SET_CLK(260kHz): SCLK(260kHz) MODE(0) DDR(0) DIV(400) DS(0) RS(0)
[SD0] Host controller intialization done
[mmc_init]: msdc0 start mmc_init_card()
[mmc_init_card]: start
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
[SD0] Switch to High-Speed mode!
[SD0] Switch to SDR buswidth
[SD0] SET_CLK(260kHz): SCLK(260kHz) MODE(0) DDR(0) DIV(400) DS(0) RS(0)
[SD0] Size: 29820 MB, Max.Speed: 52000 kHz, blklen(512), nblks(61071360)
[SD0] Initialized, eMMC45
[SD0] SET_CLK(52000kHz): SCLK(52000kHz) MODE(0) DDR(0) DIV(2) DS(0) RS(0)
[mmc_init_card]: finish successfully
#T#Boot dev init=168
[PLFM] Init Boot Device: OK(0)
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
[AB] Current boot: Preloader_a
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[QL_AB] metadata.slots[0].priority:15,metadata.slots[1].priority:0.
[AB] ab_suffix: _a, ab_retry: 0, ab_boot_success: 1
[ROM_INFO] 'v131074'

[LIB] Loading SEC config
[LIB] Name =
[LIB] Config = 0x22, 0x11
0x31,0x41,0x35,0x32
GCPU Enhance,PL_V1.4

[SEC] reading seccfg
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
0x0,0x0,0x0,0x0,0x0,0x0,0x0,0x0,
[LIB] seclib_img_auth_load_sig [LIB] CFG read size '0x2000' '0x3C'
[LIB] SEC CFG doesn't exist
[SEC] init fail '0x103000'
#T#Sec lib init=30
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
boot_part: 1
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
part name=loader_ext_a
[SEC_POLICY] reached the end, use default policy
[SEC_POLICY] sboot_state = 0x1
[SEC_POLICY] lock_state(default) = 0x4
img_auth_required=1
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
[GPT_PL]check header, err(signature 0x00000054594C5242!=0x5452415020494645)
[GPT_PL] get_gpt_header fail
sbc_en = 0
[SBC] cert verify, part = loader_ext_a, img = loader_ext_dram...fail, ret = 0x10 1017
cert vfy fail
<ASSERT> /101g/mtk/package/boot/preloader/platform/mt6890/src/core/main.c:line 1 047 0
PL fatal error...
PL delay for Long Press Reboot
[PLFM] emergency download mode(timeout: 5s).
[RGU] mtk_arch_reset at pre-loader!
[RGU] mtk_wdt_reset WDT MODE=35

Mismatched or unsigned loader_ext_a daw. kung na-remember mo po yung first firmware version after pag-receive ng device, try mo po re-flash ng loader_ext_a sa ganyang firmware version. kung mayroong firmware dump.

Concern ko din po yung [GPT_PL] get_gpt_header fail na errors. baka sira na yung eMMC mo po hshs

angel031 · Sun at 8:04 PM

Port - Hint:

Power off the phone before connecting.
For brom mode, press and hold vol up, vol dwn, or all hw buttons and connect usb.
For preloader mode, don't press any hw button and connect usb.
If it is already connected and on, hold power for 10 seconds to reset.

...........
Port - Device detected

Preloader - Detected regular mode !
Preloader - CPU: MT6880/MT6890 Modem()
Preloader - HW version: 0x0
Preloader - WDT: 0x10007000
Preloader - Uart: 0x11003000
Preloader - Brom payload addr: 0x100a00
Preloader - DA payload addr: 0x201000
Preloader - Var1: 0xa
Preloader - Disabling Watchdog...
Preloader - HW code: 0x992
Preloader - Target config: 0x5
Preloader - SBC enabled: True
Preloader - SLA enabled: False
Preloader - DAA enabled: True
Preloader - SWJTAG enabled: True
Preloader - EPP_PARAM at 0x600 after EMMC_BOOT/SDMMC_BOOT: False
Preloader - Root cert required: False
Preloader - Mem read auth: False
Preloader - Mem write auth: False
Preloader - Cmd 0xC8 blocked: False
Preloader - Get Target info
Preloader - HW subcode: 0x8a00
Preloader - HW Ver: 0xca01
Preloader - SW Ver: 0x1
Preloader - ME_ID: 037DD8FD5C8A9F6F3741DD1DFA674037
Mtk - We're not in bootrom, trying to crash da...
Exploitation - Crashing da...
Preloader
Preloader - [LIB]: upload_data failed with error: DAA_SIG_VERIFY_FAILED (0x7024)
Preloader
Preloader - [LIB]: Error on uploading da data
Preloader - Status: Waiting for PreLoader VCOM, please reconnect mobile/iot device to brom mode

Port - Hint:

Power off the phone before connecting.
For brom mode, press and hold vol up, vol dwn, or all hw buttons and connect usb.
For preloader mode, don't press any hw button and connect usb.
If it is already connected and on, hold power for 10 seconds to reset.

Port - Device detected

Preloader - Detected regular mode !
Preloader - CPU: MT6880/MT6890 Modem()
Preloader - HW version: 0x0
Preloader - WDT: 0x10007000
Preloader - Uart: 0x11003000
Preloader - Brom payload addr: 0x100a00
Preloader - DA payload addr: 0x201000
Preloader - Var1: 0xa
Preloader - Disabling Watchdog...
Preloader - HW code: 0x992
Preloader - Target config: 0xe5
Preloader - SBC enabled: True
Preloader - SLA enabled: False
Preloader - DAA enabled: True
Preloader - SWJTAG enabled: True
Preloader - EPP_PARAM at 0x600 after EMMC_BOOT/SDMMC_BOOT: False
Preloader - Root cert required: False
Preloader - Mem read auth: True
Preloader - Mem write auth: True
Preloader - Cmd 0xC8 blocked: True
Preloader - Get Target info
Preloader - BROM mode detected.
Preloader - HW subcode: 0x8a00
Preloader - HW Ver: 0xca01
Preloader - SW Ver: 0x1
Preloader - ME_ID: 037DD8FD5C8A9F6F3741DD1DFA674037
Preloader
Preloader - [LIB]: Auth file is required. Use --auth option.
PLTools - Loading payload from generic_patcher_payload.bin, 0x538 bytes
Exploitation - Kamakiri Run
Exploitation
Exploitation - [LIB]: Error on sending payload.
PLTools
PLTools - [LIB]: Error on sending payload: /home/angel/mtkclient_UnbrickThe101/mtkclient/payloads/generic_patcher_payload.bin

pano to sir error ung sending payload

angel031 · Sun at 10:57 PM

baka meron po kayong DA file

jcamanansala · Sun at 11:21 PM

angel031 said:
baka meron po kayong DA file

Same tayo paps, magkakaiba pala tayo ng hardwares so meaning may nga version tayo. Black ung motherboard ko baka sa iba is kulay green

Qawe_1423 · Mon at 5:17 PM

edcyreysase said:
Mismatched or unsigned loader_ext_a daw. kung na-remember mo po yung first firmware version after pag-receive ng device, try mo po re-flash ng loader_ext_a sa ganyang firmware version. kung mayroong firmware dump.

Concern ko din po yung [GPT_PL] get_gpt_header fail na errors. baka sira na yung eMMC mo po hshs

using WSL Ubuntu, GPT error removed by flashing Boot bin pero yung
cert vfy fail talaga TS haha. Na flash kuna loader_ext_a from

RA_MI_v7.00.02g, RA_MI_v7.2.02g and RA_MI_v7.2.03g

dump FW ni Schemix.

[LIB] Loading SEC config
[LIB] Name =
[LIB] Config = 0x22, 0x11
0x31,0x41,0x35,0x32
GCPU Enhance,PL_V1.4

[SEC] reading seccfg
0x4D,0x4D,0x4D,0x4D,0x4,0x0,0x0,0x0,
[LIB] seclib_img_auth_load_sig [LIB] CFG read size '0x2000' '0x3C'
0x4D4D4D4D
[LIB] SEC CFG 'v4' exists
[LIB] HW DEC
[SEC] init fail '0x103001'
#T#Sec lib init=20
[SD0] EXT_CSD_ERASE_GRP_DEF is Off, wp_size = 8192KB
[SD0] csd.write_prot_grpsz = 15, csd.erase_sctsz = 1024
boot_part: 1
part name=loader_ext_a
[SEC_POLICY] reached the end, use default policy
[SEC_POLICY] sboot_state = 0x1
[SEC_POLICY] lock_state(default) = 0x4
img_auth_required=1
sbc_en = 0
[SBC] cert verify, part = loader_ext_a, img = loader_ext_dram...fail, ret = 0x101017
cert vfy fail
<ASSERT> /101g/mtk/package/boot/preloader/platform/mt6890/src/core/main.c:line 1047 0
PL fatal error...
PL delay for Long Press Reboot
[PLFM] emergency download mode(timeout: 5s).
[RGU] mtk_arch_reset at pre-loader!
[RGU] mtk_wdt_reset WDT MODE=35

Qawe_1423 · Mon at 5:24 PM

TS baka may preloader dump ka pwede palapag. TY

edcyreysase · Mon at 5:31 PM

Qawe_1423 said:
TS baka may preloader dump ka pwede palapag. TY

Try ko i-extract yung akin pero wala akong SSH Access since Fusion gamit ko hshs.
Buut try ko i-boot yung rootfs ng v7.

Qawe_1423 · Mon at 6:18 PM

Ok na TS buhay na router pero stock lang sa logo try ko reset or reflash.

44.649173] <2>.(2)[18747:ccci_fsd]ccci_fsd: dev_node=/dev/ccci_fs stream_sup
[ 44.651131] <2>.(2)[18747:ccci_fsd]ccci_fsd: can't catch SIGKILL
[ 44.652034] <2>.(2)[18747:ccci_fsd]ccci_fsd: Open: [error]fail open X://md_nv
[ 44.653679] <2>.(2)[18747:ccci_fsd]ccci_fsd: Error_code=2
[ 44.655034] <2>.(2)[18747:ccci_fsd]ccci_fsd: FS_IsReadOnly: [error]fail on fi
[ 44.656515] <2>.(2)[18747:ccci_fsd]ccci_fsd: Error_code=2

OpenWrt login: [ 68.586458] <1>[name:mt_wifi&][name:mt_wifi&]7915@C00L0,CmdExtStaRecDeleteRsp() 1653: EID(0x25), CmdResult.u4Status = 0x0, StaRecValid:0 (Bss:0, Wcid:138, EleNum:1)
[ 68.711568] <2>[name:mt_wifi&][name:mt_wifi&]7915@C00L0,CmdExtStaRecDeleteRsp() 1653: EID(0x25), CmdResult.u4Status = 0x0, StaRecValid:0 (Bss:0, Wcid:138, EleNum:1)

[ 68.789797] <2>[name:mt_wifi&][name:mt_wifi&]7915@C23L0,dfs_pre_cac_detect_next_channel() 1237:
[ 68.803218] <3>[name:mt_wifi&][name:mt_wifi&]7915@C00L0,ApAutoChannelAtBootUp() 391:

OpenWrt login:

Qawe_1423 · Mon at 6:58 PM

TS ano yung way mo para mapasok brom mode? ayaw na kasi since working na stock lang sa logo
ayaw din nang reset

edcyreysase · Mon at 7:13 PM

Qawe_1423 said:
TS ano yung way mo para mapasok brom mode?

wala pa po naka-discover ng pag-boot to BROM.

ayaw na kasi since working na stock lang sa logo
ayaw din nang reset

Try mo po yung na send ko po na rootfs.

You do not have permission to view the full content of this post. Log in or register now.

angel031 · Mon at 7:44 PM

angel031 said:
Port - Hint:

Power off the phone before connecting.
For brom mode, press and hold vol up, vol dwn, or all hw buttons and connect usb.
For preloader mode, don't press any hw button and connect usb.
If it is already connected and on, hold power for 10 seconds to reset.

...........
Port - Device detected
Preloader - Detected regular mode !
Preloader - CPU: MT6880/MT6890 Modem()
Preloader - HW version: 0x0
Preloader - WDT: 0x10007000
Preloader - Uart: 0x11003000
Preloader - Brom payload addr: 0x100a00
Preloader - DA payload addr: 0x201000
Preloader - Var1: 0xa
Preloader - Disabling Watchdog...
Preloader - HW code: 0x992
Preloader - Target config: 0x5
Preloader - SBC enabled: True
Preloader - SLA enabled: False
Preloader - DAA enabled: True
Preloader - SWJTAG enabled: True
Preloader - EPP_PARAM at 0x600 after EMMC_BOOT/SDMMC_BOOT: False
Preloader - Root cert required: False
Preloader - Mem read auth: False
Preloader - Mem write auth: False
Preloader - Cmd 0xC8 blocked: False
Preloader - Get Target info
Preloader - HW subcode: 0x8a00
Preloader - HW Ver: 0xca01
Preloader - SW Ver: 0x1
Preloader - ME_ID: 037DD8FD5C8A9F6F3741DD1DFA674037
Mtk - We're not in bootrom, trying to crash da...
Exploitation - Crashing da...
Preloader
Preloader - [LIB]: upload_data failed with error: DAA_SIG_VERIFY_FAILED (0x7024)
Preloader
Preloader - [LIB]: Error on uploading da data
Preloader - Status: Waiting for PreLoader VCOM, please reconnect mobile/iot device to brom mode

Port - Hint:

Power off the phone before connecting.
For brom mode, press and hold vol up, vol dwn, or all hw buttons and connect usb.
For preloader mode, don't press any hw button and connect usb.
If it is already connected and on, hold power for 10 seconds to reset.

Port - Device detected
Preloader - Detected regular mode !
Preloader - CPU: MT6880/MT6890 Modem()
Preloader - HW version: 0x0
Preloader - WDT: 0x10007000
Preloader - Uart: 0x11003000
Preloader - Brom payload addr: 0x100a00
Preloader - DA payload addr: 0x201000
Preloader - Var1: 0xa
Preloader - Disabling Watchdog...
Preloader - HW code: 0x992
Preloader - Target config: 0xe5
Preloader - SBC enabled: True
Preloader - SLA enabled: False
Preloader - DAA enabled: True
Preloader - SWJTAG enabled: True
Preloader - EPP_PARAM at 0x600 after EMMC_BOOT/SDMMC_BOOT: False
Preloader - Root cert required: False
Preloader - Mem read auth: True
Preloader - Mem write auth: True
Preloader - Cmd 0xC8 blocked: True
Preloader - Get Target info
Preloader - BROM mode detected.
Preloader - HW subcode: 0x8a00
Preloader - HW Ver: 0xca01
Preloader - SW Ver: 0x1
Preloader - ME_ID: 037DD8FD5C8A9F6F3741DD1DFA674037
Preloader
Preloader - [LIB]: Auth file is required. Use --auth option.
PLTools - Loading payload from generic_patcher_payload.bin, 0x538 bytes
Exploitation - Kamakiri Run
Exploitation
Exploitation - [LIB]: Error on sending payload.
PLTools
PLTools - [LIB]: Error on sending payload: /home/angel/mtkclient_UnbrickThe101/mtkclient/payloads/generic_patcher_payload.bin

pano to sir error ung sending payload

TS baka may resolution ka dito

jcamanansala · Mon at 7:52 PM

Qawe_1423 said:
TS ano yung way mo para mapasok brom mode? ayaw na kasi since working na stock lang sa logo
ayaw din nang reset

Try mo UART paps, sa akin automatic brom mode un.

Qawe_1423 · Mon at 8:49 PM

jcamanansala said:
Try mo UART paps, sa akin automatic brom mode un.

Pano paps? naka UART nako

jcamanansala · Mon at 8:58 PM

Qawe_1423 said:
Pano paps? naka UART nako

Lagyan mo daw ng --serialport python command mo

--serialport COM# <~~~ uart com port no.

Qawe_1423 · Mon at 9:36 PM

jcamanansala said:
Lagyan mo daw ng --serialport python command mo

--serialport COM# <~~~ uart com port no.

ayaw paps. since hindi na naka DL mode yung router dina na didetect usb sa PC

Globe RainX The101 Bricked

Enthusiast

Grasshopper

Leecher

Leecher

Grasshopper

Grasshopper

Enthusiast

Enthusiast

RA_MI_v7.00.02g, RA_MI_v7.2.02g and RA_MI_v7.2.03g ​

Enthusiast

Leecher

Enthusiast

Enthusiast

Leecher

Grasshopper

Enthusiast

Enthusiast

Enthusiast

Enthusiast

Similar threads

About this Thread

Trending Topics

Online now

Forum statistics

RA_MI_v7.00.02g, RA_MI_v7.2.02g and RA_MI_v7.2.03g
