Clicker MEP Opening 1.0.0

[DrZero]

File size: 14.1 MB

This tool is purposefully crafted to create openings in structure and architectural models for MEP elements in linked Autodesk® Revit® Models with a single click.



Efficiently create openings in both architectural and structural models for MEP links.
Select special categories (Cable Trays, Ducts, ***** and Conduits) from MEP links to create an opening.
The tool considers insulation and calculates it automatically when creating openings and adds to clearance and element size.
Select special categories (Both Structural and Architectural (Walls, Floors and Ceilings)) from the open model.
Easily set clearance for each category as per your requirements (For both Structural and Architectural).
Openings are created only for active view.
Openings are created only for loaded links.
Can create openings for Walls, Structure Slab, Floors and ceilings (For both Structural and Architecture).
Support for circular and Rectangular opening.
Export Bill of Quantities (BOQ) for both new and existing openings.

Compatible with
Autodesk Revit
Version: 2025 , 2024 , 2023 , 2022 , 2021 , 2020
