DQ Projects BreakerWiring 1.0.0

[DrZero]

File size: 2.56 MB

BreakerWiring is an Autodesk® Revit® plugin designed to streamline electrical design by automatically calculating the appropriate breaker standard rating, wire conductor size, and conduit dimensions based on the NEC NFPA 70 standard.
​

Leveraging the parameters of electrical power circuits, this plugin ensures compliance with industry standards.

Additionally, BreakerWiring enables users to easily assign multiple shared parameters to each electrical circuit, enhancing project efficiency and consistency across designs.

BreakerWiring allows the user to control shared parameters with several factors such as permissible voltage drop, derating factor as number of circuits and temperature, and wiring.
