❓ Help Engineering question

[Akame31]

sa mga engineers or architect diyan paano yung illustration ng 3 bays per frame? Salamat.



[PHC - Royal]

Basis.



[Akame31]

Basis.

Kung ganyan po lods paano makakabuo ng 3 bays sa isang frame?



[PHC - Royal]

Kung ganyan po lods paano makakabuo ng 3 bays sa isang frame?

Plan of structural models with (a) 4 bays, (b) 3 bays and (c) 2 bays (unit: m)



[Akame31]

View attachment 1778552​

Plan of structural models with (a) 4 bays, (b) 3 bays and (c) 2 bays (unit: m)

Ayown thank you po <3
