PHPentalogix Cammaster 11.24.79 (x64)
File size: 83.2 MB
PentaLogix's most complete CAM software designed to meet tomorrow's manufacturing needs. CAMMaster uses scripting, raster and contour based algorithms and increased ease-of-use to deliver the strongest PC-Based CAM system in the industry. We provide you a USB dongle. CAMMaster can be installed on multiple computers but will only run on a computer that has the dongle plugged in.
Highlights
Visual Basic(r) compatible scripting
Includes RoutMaster- NC drill & Rout editing
Raster based netlist extraction
Contour based netlist extraction
Advanced DFM checks
Automated aperture conversion
Layer comparison
NetConvert
Support for AOI machines (CAMTEK, Lloyd-Doyle)
CAMMaster is a COM (ActiveX) accessible object
Automated draw-to-flash conversion
Netlist comparison
Routing Path generation, with routing tabs
Soldermask generation
Copper pouring
Silkscreen clipping
Venting & thieving
One year of free technical support
And, much more!
CAMMaster is the premier product for the most demanding jobs. CAMMasters' scripting feature allows you to automate your routine jobs, improve accuracy and yields, as well as get the work done faster. Experience the best tool in the industry to get your jobs done. Panelization is a snap with all the features available in this package. Netlist extraction and DRC set the industry standard.
CAMMaster utilizes robust scripting capabilities designed to automate your processes. Unleash CAMMaster's potential by allowing our PentaLogix Technicians to custom script your operations. CAMMaster's scripting capabilities give you the same promise and potential of other CAM products on the market without the high cost! Scripting possibilities are essentially endless: custom auto panelization, job setup, DRC and Netlist extract, export and prepare for test, all at the touch of a button.
CAMMaster Network License Server
CAMMaster can also be purchased as a network server version which allows for the sharing of CAMMaster Network Licenses among mulitple clients. In order to run CAMMaster Network Version, the CAMMaster must be installed on your client computers. You may install the applications on as many computers in your network as you wish. The License Server will administer licenses to the clients when the programs are started. The number of clients who can run the software at the same time depends on the number of licensed users recorded in the license on the server. So, if you have a license for 5 users, 5 different client computers can check out a license at the same time. If the 6th tries, it will fail.
